Truck Model

ZZ3257N364GB1

Truck Brand

SINOTRUK –HOWO

Driving type

Left Hand driving

Dimension(Lx W xH)（unloaded）（mm）

8130x2500x3300

Cargo body size (L*W*H)

5200x2300x1400 20m3

Cargo body thickness(mm)

bottom:8mm, side:6mm

Lift type of Carriage

Ventral side lifting

Wheel base (mm)

3825+1350

Loading Weight（kg）

25000

Fuel tanker capacity(L)

300L with locking fuel cap

Clutch

Single-plate dry clutch Φ430mm

Engine Model

Model

WD615.69

Horse Power

336HP，273KW/2200

Emission

EURO II

Fuel Type

Diesel

Transmission

Model

HW19710,10 forwards and 2 reverse

Brake system

Service brake

Dual circuit compressed air brake

Parking brake

spring energy, compressed air operating on rear wheels

Auxiliary brake

Engine exhaust brake

Steering system

Model

hydraulic steering with power assistance
Ratio：22.2-26.2

Front axle

HF9

Rear axle

HC16

Color

Optional

Tire

12.00R20 Steel tires， 10+1 spare

Electrical system

Operating voltage

24V,negative grounded

Starter

24V,7.35KW

Alternator

28V,1500W

Batteries

2*12V.165Ah

Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light.

Cab

TX-F cab, (single sleeper, with air-condition)
