Specifications | |
Dimension | 12.4m×2.50m×1.55m (Outside) |
Payload | 40T |
Tare weight | About 6.5 T |
Twist lock | 12uints |
Chassis | |
Main beam | Heavy duty and extra durability designed I beam; Opting for high tensile steel T700, welded by automatic Submerged-Arc processes. |
Frame Beam | Top Flange 12mm,width 140mm; Middle Flange 8mm; Bottom Flange 12mm,width 140mm, main beam height 500mm |
Frame Floor | The Thickness is 3mm pattern |
Axle | 3 axles, 13Ton 16ton brake pads |
Landing Gear | Fuwa BRAND 28T lifting capacity with two speed |
King Pin | 2.00 inch bolt-in king pin |
Suspension | Mechanical suspension reinforced type |
Leaf Spring | 90mm(W)*13mm(T)*10 Layer |
Pneumatic Braking System | Dual line pneumatic brake system,T30 air chamber ,40L x2 air tanks, Emergency relay valve |
Rim | 9.0-20*13 pcs |
Tire | 12R22.5*13 pcs Triangle tire |
Accessories | One standard tool box |
Spare tire rack | One |
Electrical system | 24 volt electrical system.7 pin electrical connector. Parking stop, reverse, number plate and indicator lights. rear lights conform to European standard, rear front and side reflectors |
